Introduction to Thermogravimetric Analyzer (TG) Techniques

TG is the instrument to obtain the weight of a substance as a function of time and/or temperature.
TGA is conducted in a carefully controlled thermal environment to achieve reliable and reproducible results.
TGA measurement has many applications in physical and chemical characterization because of its precise weight change detection capability.
TGA atmosphere can be modified as well, with the most common options being inert or oxygen-rich.

Key Features of SEO's TGA

High Mass(200gram)
High volume
High Temperature
Versatile reaction gas type
Real time&powerful data analysis tools

High mass
It’s definitely needed when looking at very small amount of component, such as coatings, additives, inorganic residue, corrosion, oxidation, in the weight % less than 0.5 %.  Also it’s needed when dealing with heterogeneous samples.

High volume
To accommodate the high density samples (high mass - high volume sample, or whole parts), low density samples (low mass – high volume, such as gel, foams), and expandable samples.

Versatile Reaction gas types
Corrosive, flammable, and combustible gases.

TGA P-1200 Series ​

SEO TGA Series!

TGA P-1200

Balance
Max Load: 200 g
Sensitivity: 1 mg (or 0.1 mg )
Temperature Range:  RT to 1200 °C
Sample Volume: up to 50 ml
Reactor Tube, 38 mm: Quartz

P-1500

Balance
Max Load: 200 g
Sensitivity: 1 mg (or 0.1 mg)
Temperature Range:  RT to 1500 °C
Sample Volume: up to 50 ml
Reactor Tube, 38 mm: Alumina
Customizing system
